All-in-one Machine

The All-in-one Machine covers a range of multifunctional testing and diagnostic tools that integrate multiple features into a single compact unit. These machines are designed to improve field efficiency, reduce equipment switching, and meet the diverse needs of fiber optic, network, and engineering professionals. Ideal for installation, maintenance, and troubleshooting tasks.

Home > All-in-one Machine

Product Advantage

Optical Power Meter

Support Memory Wavelength Function

Support Lighting

Support Storage of Test Data

Support Timed Shutdown

Support Backlight Switch

Specifications

G9

GUANGYAN-G9

Red Light Wavelength: 650(nm)

Red Light Power: 5, 15, 20, 30mW (optional)

GUANGYAN-G9

This all-in-one device integrates red light source, optical power meter, LED flashlight, and USB charging. Ideal for fiber optic line testing, fault location, and power measurement. It supports 800–1700nm wide wavelength range, SC/FC/ST interfaces, and offers excellent durability with its protective housing and adjustable stand.

Learn More

Red Light Wavelength	650(nm)
Red Light Power	5, 15, 20, 30mW (optional)
Wavelength Range	800 to 1700
Standard Wavelength	850 \ 980 \ 1270 \ 1300 \ 1310 \ 1490 \ 1550 \ 1557 \ 1625(nm)
Detector Type	InGaAs
Measuring Range	-70\+6 , -5 0\+26
Uncertainty	±5%
Display Resolution	Linearity display: 0.1%; Logarithmic display: 0.01dBm
Frequency Identification	270, 1000, 2000Hz
Wireless Module	2G (Optional)
Number of Saved Data	20(PCS)
Input Voltage	3~6V
Working Temperature	-10~+60℃
Storage Temperature	-25~+70°C
Auto Shutdown	10min
Working Time	≥48H
Instrument Size	142* 76* 30(mm)
Package Size	172* 77 * 40(mm)
Net Weight of the Instrument	212/224g
Electricity Power Source	3x 5 batteries (optional eightrechargeable lithium batteries)tio ha ) \ Exte rnal 6 hpu tU SB

Y1

GUANGYAN-Y1

Connector Compatibility: SC, ST, FC adapter compatible

Memory Function: Saves last used wavelength after shutdown

GUANGYAN-Y1

This multifunctional tester supports 9 wavelength options and 3 types of fiber connectors (SC/FC/ST). It features a drop-resistant design, user self-calibration, and memory for wavelength settings. The adjustable screen backlight includes smart, on, and off modes, enhancing readability in various environments.

Learn More

Wavelength Selection	Supports 9 wavelengths: 850 / 980 / 1270 / 1300 / 1310 / 1490 / 1550 / 1557 / 1625nm
Connector Compatibility	SC, ST, FC adapter compatible
Memory Function	Saves last used wavelength after shutdown
Backlight Modes	3 modes: Always On / Off / Smart (auto off in 1 min)
Red Light Modes	Continuous & Intermittent visual fault locator
Replaceable Ceramic Core	Replace front ceramic core manually
Power Units Display	Toggle between mW / dBm / dB + dBm
Drop-Proof Protection	Silicone housing for shock protection
Automatic Frequency Recognition	Auto detect fiber modulation after cable is inserted

Y3

GUANGYAN-Y3

Wavelength Range: 800 to 1700

Connector: FC/SC/ST

GUANGYAN-Y3

This optical power meter features a six-layer intelligent protection system, effectively safeguarding against electrical hazards. Designed to meet strict industrial standards, it ensures stable and long-lasting operation even in harsh environments, making it ideal for field applications.

Learn More

Wavelength Range	800 to 1700
Connector	FC/SC/ST
Detector Type	Ingaas
Measuring Range	Type A: (-70+6) / Type B: (-50+26), other measurement ranges can also be customized
Uncertainty	±0.2dB
Standard Wavelength	850, 980, 1270, 1300, 1310, 1490, 1550, 1577, 1625nm
Display Resolution	Linear display: 0.1% ; Logarithmic display: 0.1dBm
Red Light Working Wavelength	650nm
Red Light Power	>5mW/15mW
Operating Temperature	-10 to+60 ℃
Storage Temperature	-25 to+70 C
Automatic Shutdown Time	10 minutes
Battery Duration	≥48 hours
Instrument Size	1186830mm
Power Supply	Built in lithium battery (rechargeable)/7-size battery *2(powered)/USB external power supply

Y8

GUANGYAN-Y8

Wavelength Range: 800 to 1700

Measurement Range: -70 to +6, -70 to +10, -50 to +26

GUANGYAN-Y8

This multifunctional tester integrates various measurement tools, offering intelligent detection and precise readings. With features like network cable testing, precise line finding, an optical power meter, laser rangefinder, and high-precision capabilities, it meets the needs of both basic and advanced applications.

Learn More

Wavelength Range	800 to 1700
Measurement Range	-70 to +6, -70 to +10, -50 to +26
Standard Wavelength (nm)	850, 980, 1300, 1310, 1490, 1550, 1625
Display Resolution	Linearity display: 0.1%; Logarithmic display: 0.01dBm
Operating Wavelength of Red Light	650nm
Uncertainty	±2%
Red Light Power	5,10(20, 30 customizable)
Frequency Identification	0, 270, 1000, 2000Hz
RJ45 Seeking Distance	200m
Laser Range Distance	40m
Input Voltage	3~6V
Auto-off Time	10 minutes
Battery Capacity	1100mAh rechargeable lithium battery
Continuous Working Time	Approx. 72 hours (single power measurement)
Instrument Size	115* 71*30 mm
Package Size	1709547 mm
Net Weight of the Instrument	145g

Y9

GUANGYAN-Y9

Wavelength Range: 800~1700

Detector Type: -70~+6, -70~+10, -50~+26 (optional)

GUANGYAN-Y9

This multifunctional tester integrates an optical power meter, network cable tester, strong red light source, and LED lighting. It features a 2.4-inch HD color screen, 4G Wi-Fi for real-time data upload, and supports 9 wavelengths with memory functions. Designed for high-precision measurements and efficient testing.

Learn More

Wavelength Range	800~1700
Detector Type	-70~+6, -70~+10, -50~+26 (optional)
Standard Wavelength	850 / 980 / 1270 / 1300 / 1310 / 1490 / 1550 / 1577 / 1625
Display Resolution	Linear display: 0.1%; Logarithmic display: 0.01dBm
VFL Wavelength	1 650nm
Uncertainty	±5%
VFLpower	5 / 15 / 20 / 30(optional)
Frequency Identification	0, 270, 1000, 2000Hz
Wireless Module Type	4G (optional)
Data Storage	100(PCS)
Input Voltage	3~5V
Automatic Shutdown	10min
Power Supply	5 batteries *2 (optional), Rechargeablelithium battery (optional), External Inputs
Continuous Workingtime of Battery	20h
Instrument Size	1427331mm
Net Weight of Meter	375~455g
