Fiber Fusion Splicer
Fiber Fusion Splicers are essential tools for precise and efficient optical fiber connection. They use advanced alignment and heating technologies to fuse fiber cores with minimal signal loss, ensuring high-performance network installations in telecom, data centers, and industrial applications.
Home >
Product Advantage
Fusion Splicer
Support Password Setting and Renal Function
Six Motor Fully Automatic
5-Inch High Definition Touch Screen
8 Seconds for Fusion 18 Seconds for Heating
7800mAh Capacity Battery
Specifications
- K5
- M5
- K3
- K3S
GUANGYAN-K5
The K5 Intelligent Fiber Optic Fusion Splicing Machine is designed for high-efficiency, on-site optical splicing. It supports preheating without waiting, delivers ultra-fast fusion in 8 seconds, and heating in just 18 seconds.
Learn More
| Applicable Optical Fiber | SMF(G.652), MMF(G.651), DSF(G.653), NZDSF(G.655) |
| Fiber Diameter | Cladding layer: 80-150μm; Coating layer: 0.1-3mm |
| Splicing Loss | 0.02dB(SMF), 0.01dB(MMF), 0.04dB(DSF/NZDSF)measured by ITU-I shear method |
| Alignment Method | Fiber core, cladding |
| Focusing Method | Six motors auto-focus |
| Splicing Method | Automatic / Manual |
| Splicing Time | 8s (SMF typical) |
| Relay Test | 1.96-2.25N |
| Screen Display | Capacitive 5.5″touchscreen LCD |
| Magnification | 300 (X/Y),150 (X/Y synchronization) |
| Splicing Record | 1000 groups |
| Typical Heating Time | 18S |
| Heating Time | 0-60S |
| Heat Shrink Sleeve | 20mm, 30mm, 40mm, 50mm, 60mm |
| OPM | Range(dBm): -70~+3/Wavelength: 850nm-1625nm/Uncertainty: ≥0.5% |
| VFL | ≥10mW |
| Operation Interface | GUI graphical user interface |
| System Upgrade | USB Upgrade |
| Electrode Rod Life | 3000 times |
| Lighting Method | Automatic / Manual |
| Battery Capacity | 7800mAh |
| Charging Time | ≤3.5h |
| Output Voltage | DC 11.1V |
| USB Port Output | 5V/500mA |
| Charger | Input: AC 100-240V,50/60Hz, Output: DC13.5V/4A |
| Working Environment | Temperature: -15℃-+50℃ /Humidity:≤95%RH(no condensation) /Altitude:0-5000m /Wind speed:≤15m/s |
| Storage Conditions | Temperature: -40℃-+80℃ / Humidity: 0-95% |
| Size | Length × width × height: 190mm ×146mm × 117mm |
| Weight | 1.74kg (with battery), 1.24kg (without battery) |
GUANGYAN-M5
This intelligent fully automatic fiber fusion splicer features a built-in red light source and optical power meter with six-wavelength support and auto-calibration. With a six-motor drive system and a 180° rotatable high-resolution touchscreen, it ensures fast, precise, and user-friendly operation in demanding field conditions.
Learn More
| Alignment Mode | Fiber core and cladding | VFL | ≥10MW |
| Focusing Mode | Six motors auto focus | Operating Interface | GUl graphical user operation interface |
| Welding Mode | Automatic/manual | Electrode Life | 3000 times |
| Welding Time | 8s(typical SMF value) | Lighting Mode | Automatic/manual |
| Tension Test | 1.96-2.25N | Heating Time | 0-60s |
| Image Display | Capacitive 4.3″touch LCD screen | Charging Time | ≤3.5h |
| Magnification | 300(X/Y),150(X/Y synchronization) | Output Voltage | DC11.1V |
| Welding Record | 10000 groups(1000 pictures) | USB Port Output | 5V/500mA |
| Typical Heating Time | 18s | Fiber Diameter | Cladding: 80-150um, coating layer: 0.1-3mm |
| Applicable Optical Fiber | SMF(G.652), MMF(G.651), DSF(G.653), NZDSF(G.655) | ||
| Connection Loss | 0.02dB(SMF), 0.01dB(MMF), 0.04dB (DSF/NZDSF) are measured by lTU-Ishearmethod | ||
| Heat Shrink Tube Sleeve | 20mm, 30mm, 40mm, 50mm, 60mm | ||
| Local OPM | Range (dBm):-70~+6; Wavelength: 850nm~1625nm; Uncertainty:±5% | ||
| Battery Capacity | 5200mAh (Typical value of 200 welding and heating cycles) | ||
| Charger | Input: AC 100~240V, 50/60Hz, output: DC13.5V/4A | ||
| Working Environment | Temperature: -15C~+50C; humidit: ≤95%RH (nocondensation); altitude: 0~5000m | ||
| Storage Condition | Temperature: -40℃~+80℃; humidity: 0~95% | ||
| Size of Welding Machine | 156mm*155mm*152mm | ||
| Weight of Welding Machine | 1.74kg | ||
GUANGYAN-K3
The High Precision Fiber Fusion Splicer provides a reliable and fast solution for optical fiber splicing, with support for fully automatic, semi-automatic, and manual modes. It features quick fusion times, a high-definition display, and is equipped with a versatile clamp for various fiber types. Ideal for both professional installation and maintenance tasks.
Learn More
| Applicable Fiber Optic | SMF(G.652)/MMF(G.651)/DSF(G.653)/NZDSF(G.655) |
| Fiber Diameter | Cladding: 80-150uM; soil cover layer: 0.1-3mm |
| Splice Loss | 0.02dB(SMF)/0.01dB(MMF)/0.04dB(DSF/NZDSF) |
| Battery Capacity | 5200mAh |
| Focusing Method | Four motor focus |
| Sealing | Auto/semi-automatic/Manual |
| Weld Time | 8 seconds (typical SMF value) |
| Relay Testing | 1.96-2.25N |
| Image Display | Cap acitive 5-inch touch LCD screen |
| Magnification | 300 (X/Y)/150 (X/Y synchronization) |
| Welding Record | 10000 welding data and 1000 images |
| Typical Heating Time | 18S(optional) |
| Heating Time | 0-60S |
| Heat Shrinktu-bing Sleeve | 20mm/30mm/40mm/50mm/60mm |
| Operation Interface | GUI graphical user interface |
GUANGYAN-K3S
This advanced fiber fusion splicer integrates a red light source (VFL) and optical power meter (OPM) into one compact machine, supporting six wavelengths with self-calibration and large data storage. Equipped with a three-in-one clamp, high-speed fusion, large battery, and intelligent interface, it offers an efficient, all-in-one solution for optical fiber installation and maintenance.
Learn More
| Applicable Fiber Optic | SMF(G.652)/MMF(G.651)/DSF(G.653)/NZDSF(G.655) |
| Fiber Diameter | Cladding: 80-150uM; soil cover layer: 0.1-3mm |
| Splice Loss | 0.02dB(SMF)/0.01dB(MMF)/0.04dB(DSF/NZDSF) |
| Alignment Method | Fiber core, cladding |
| Focusing Method | Four motor automatic focusing |
| Sealing | Auto/semi-automatic/Manual |
| Weld Time | 8 seconds (typical SMF value) |
| Relay Testing | 1.96-2.25N |
| Image Display | Cap acitive 5-inch touch LCD screen |
| Magnification | 300 (X/Y)/150 (X/Y synchronization) |
| Welding Record | 10000 welding data and 1000 images |
| Typical Heating Time | 18S(optional) |
| Heating Time | 0-60S |
| Heat Shrinktu-bing Sleeve | 20mm/30mm/40mm/50mm/60mm |
| Red Light (VFL) | ≥10mW |
| Operation Interface | GUI graphical user interface |
