Fiber Optic Identification

Fiber optic identification devices are essential tools for detecting live optical signals without disrupting the fiber. They enable technicians to identify signal presence, direction, and frequency in real time, supporting efficient maintenance, troubleshooting, and deployment.

Home > Fiber Optic Identification

Product Advantage

Fiber Optic Identification Device

Multiple Diameter Optical Fibers Can Be Measured Without Replacing the Fiber Clamp Head

Detecting the Direction of Fiber Optic Signals

Detecting Fixed Frequency Signals Loaded in Optical Signals

Specifications

S2

GUANGYAN-S2

Recognize Wavelength Range (nm): 850~1700

Probe Type: InGaAs

GUANGYAN-S2

This electric fiber optic identification device integrates hidden red light source, high-brightness LED, and micro-bending testing technology. Designed for quick on-site fiber identification and signal frequency detection, it supports one-click operation, multiple charging methods, and universal cable compatibility, making it ideal for professional fieldwork.

Learn More

Recognize Wavelength Range (nm)	850~1700
Probe Type	InGaAs
Motor Type	DC motor
Display Screen	1.77 inch FTF color screen
Adapter Type(mm)	Ф0.25 (for bare fiber), Ф0.9, Ф2.0, Ф3.0 (for pigtail)
Modulation Frequency	CW, 270, 1K, 2K
Signal Direction Indication	Left and right, above the screen, direction indication
Signal Check Range (dB m, CW/0.9mm)	-40~10(1550nm) -30~10(1310nm)
Frequency Check Range (dB m, average)	-35~10
Insertion Loss (dB m, typical)	0.8(1310nm),2.5(1550nm)
Power Supply	Rechargeable Lithium Battery
Charging Voltage (V)	5
Charging Current (A)	≤1.6
Quiescent Current (μA)	≤18
Work Frequency	≥1000 times
Li-ion Battery Capacity (mAh)	800
Automatic Shutdown (min)	10
Dimension (mm)	1605035
Weight (g)	200
