Optical Power Meter
An Optical Power Meter is a precision instrument designed to measure the absolute optical power in a fiber optic network and assess signal loss accurately. It is widely used in fiber installation, maintenance, and troubleshooting tasks.
Home >
Product Advantage
Optical Power Meter
Support Memory Wavelength Function
Support Lighting
Support Fiber Optic Work Recognition
Support Timed Shutdown
Support Backlight Switch
Specifications
- G1
- G2
- G5
- G7
- G9
- G10
- G11
- Y9
GUANGYAN-G1
The Fiber Optical Power Meter is a high-precision instrument designed for accurate measurement of optical power in fiber networks. It supports multiple wavelengths and connector types, making it suitable for various testing environments.
Learn More
| Instrument Type | (Type A) | (Type B) |
| Wavelength Range | 800~1700 | 800~1700 |
| Connector | FC/SC | FC/SC |
| Probe Type | InGaAs | InGaAs |
| Power Measurement Range | -70~+6 dbm | -50~+26 dbm |
| Uncertainty | ±5% | |
| Standard Wavelength(nm) | 850, 980, 1300, 1310, 1490, 1550, 1625 | |
| Display Resolution | Linear display: 0.1% Logarithmic display: 0.01dBm | |
| Operating Temperature(℃) | -10~+60 | |
| Storage Temperature(℃) | -25~+70 | |
| Automatic Shutdown Time(min) | 10 | |
| Battery Duration(h) | ≥48 | |
| Overall Dimension(mm) | 190×100×48 | |
| Power Supply | No.5 battery ×3 | |
| Weight(g) | 400 | |
GUANGYAN-G2
The Mini Flip Cover Optical Power Meter is a compact, ergonomic testing tool tailored for precise fiber optic power measurement. Featuring a flip design, OLED HD display, long battery life, and multi-wavelength support, it provides high accuracy and user-friendly operation for technicians in various environments.
Learn More
| Model | SGM70-A | SGM50-B |
| Power Test Range | -70~+3 | -50~+20 |
| Connector | FC/SC/ST | |
| Probe Type | InGaAs | |
| Uncertainty | ±5% | |
| Standard Wavelength (nm) | 850, 980, 1300, 1310, 1490, 1550, 1625 | |
| Display Resolution | Linearity display: 0.1% Logarithmic display: 0.01dBm | |
| Illumination Brightness | 5000mcd | |
| Input Voltage(V) | 3~6 | |
| Operating Temperature(°C) | -10~+60 | |
| Storage Temperature(°C) | -25~+70 | |
| Auto-off Time(min) | 10 | |
| Battery Duration(h) | ≥120 | |
| Instrument Size(mm) | 131*40*19 | |
| Power Dupply | Rechargeable lithium batteries | |
| Weight(g) | 53 | |
GUANGYAN-G5
The Mini Optical Power Meter is a multifunctional tool for precise fiber signal detection and network cable testing. Equipped with upgraded keys, OLED display, LED lighting, and RJ45 test capabilities, it integrates essential features in a compact, user-friendly design suitable for engineers working in diverse environments.
Learn More
| Wavelength Range | 800 to 1700 |
| Connector | FC/SC/ST |
| Detector Type | Ingaas |
| Measurement Range | TypeA: (-70to+3) / TypeB: (-50 to+20), other measurement ranges can be customized. |
| Uncertainty | ±5% |
| Standard Wavelength (nm) | 850nm, 980nm, 1300nm, 1310, 1490nm, 1550, 1625nm |
| Display Resolution | Linearity display: 0.1% Logarithmic display:0.01dBm |
| Operating Temperature(℃) | -10 to +60 |
| Storage Temperature(℃) | -25 to +70 |
| Auto-off Time(min) | 10 minutes |
| Battery Duration(h) | >48 |
| Instrument Size(mm) | 118*68*30 |
| Electricity Power Source | Built-in lithium battery (rechargeable)/ No.7battery*2(can be powered) |
| Weight(kg) | 0.14kg |
GUANGYAN-G7
This Smart Optical Power Meter is equipped with a vivid LCD color screen for clear readings, designed for precise optical fiber signal testing in engineering and fieldwork. It supports multi-wavelength recognition, high-accuracy measurement, and features durable construction with ABS engineering plastic.
Learn More
| Power Measurement Range | -70~+6/-70~+10/-50~+26 (dbm) | ||
| Standard Wavelength (nm) | 850, 980, 1270, 1300, 1310, 1490, 1550, 1557, 1625nm | ||
| Display Resolution | Linearity display:0.1% Logarithmic display:0.01dBm | ||
| Detection Area | 300(um) | Power Supply Type | Lithium battery |
| Probe Type | InGaAs | Endurance Time | ≥13 |
| Wavelength Range | 800~1700 | Charging Voltage | 5V |
| Interface Type | 2.5mm | Product Size | 127*45*20 (mm) |
| Operating Temperature | 10℃~+60℃ | Drop Height | ≤2 (m) |
| Storage Temperature | -25 ~+70℃ | Net Weight | 87g |
GUANGYAN-G9
This all-in-one device combines an optical power meter and a visual fault locator in a compact unit. It supports 9 types of wavelengths, features a bright LCD display with backlight, and includes a powerful red light source and LED flashlight for low-light environments.
Learn More
| Red Light Wavelength | 650 nm |
| Red Light Power | 5, 15, 20, 30 mW (Optional) |
| Wavelength Range | 800 to 1700 |
| Standard Wavelength | 850, 980, 1270, 1300, 1310, 1490, 1550, 1557, 1625 nm |
| Detector Type | InGaAs |
| Measuring Range | -70±6, -50±26 |
| Uncertainty | ±5% |
| Display Resolution | Linearity display: 0.1%; Logarithmic display: 0.01 dBm |
| Frequency Identification | 270, 1000, 2000 Hz |
| Wireless Module | 2G (Optional) |
| Number of Saved Data | 20 PCS |
| Input Voltage | 3~6V |
| Working Temperature | -10°C to +60°C |
| Storage Temperature | -25°C to +70°C |
| Auto Shutdown | 10 min |
| Working Time | ≥48H |
| Instrument Size | 142 × 76 × 30 mm |
| Package Size | 172 × 77 × 40 mm |
| Net Weight of Instrument | 212 / 224 g |
| Power Source | 3 × 5 batteries (optional rechargeable lithium batteries); External input USB |
GUANGYAN-G10
This compact optical power meter supports seven test wavelengths and features a high-definition digital display with dual backlight modes. Designed with a pop-up protective cover and built-in LED flashlight, it’s suitable for a wide range of work environments. The USB direct charge function and intelligent wavelength memory enhance usability for on-site testing.
Learn More
| Standard Wavelength | 850/980/1300/1310/1490/1550/1625nm |
| Probe Type | lnGaas |
| Measuring Range | -70~+6\-70~+10\-50~+26 |
| Display Resolution | Linear display: 0.1%; Logarithmic display: 0.01dBm |
| Uncertainty | ±5% |
| Battery Life | ≥20H |
| Frequency Identification | 0Hz, 270 Hz, 1000 Hz, 2000Hz |
| Charging Duration | ≤3H |
| Charging Voltage/Current | 5V/≤500mA |
| Automatic Shutdown Time | 10 minutes |
| Power Supply Mode | Built-in lithium battery, USB port |
| Battery Capacity | 400mAh |
| Net Weight | 52g |
| Packing Size | 56*35*148mm |
| Product Size | 34*17*125mm |
GUANGYAN-G11
The multifunctional optical power detector offers support for 9 wavelengths, including the new 5G measurement wavelength. It features automatic wavelength recognition, intelligent memory, and a built-in LED flashlight for dark environments. With a durable, ergonomic design and USB charging, this device is perfect for various testing needs. It is equipped with a high-strength ABS plastic body, CNC integrated molding, and soft silicone grips for comfort and durability.
Learn More
| Wavelength Range | (800~1700)nm |
| Connector | ST FC/SC (General) |
| Detector Type | lnGaAs |
| Measurement Range | (-70~+6) (-70~+10) (-50~+26) |
| Output Wavelength | 850nm, 980nm, 1270nm, 1300nm, 1310nm, 1490nm,1550nm, 1577nm, 1625nm |
| Static Current | ≤18uA |
| Operating Current | ≤25mA |
| Power Supply | Rechargeable lithium batteries 350mA |
| Uncertainty | ±5% |
| Charging Voltage | 5V |
| Charging Time | ≤3h |
| Meter Size | 172*40*28mm |
| Display Resolution | Linearity display: 0.1%; Logarithmic display: 0.01dbm |
GUANGYAN-Y9
This multifunctional optical power meter integrates five key functions—optical power testing, red light detection, LED lighting, network cable testing, and temperature detection. It supports 9 wavelengths with memory function, provides fast USB Type-C charging, and features a high-definition 2.4-inch color screen. With a compact PC+ABS housing, it ensures durability, portability, and accuracy, making it ideal for field communication testing and maintenance.
Learn More
| Wavelength Range | 800~1700 |
| Detector Type | -70~+6, -70~+10, -50~+26(optional) |
| Standard Wavelength | 850/980/1270/1300/1310/1490/1550/1577/1625 |
| Display Resolution | Linear display:0.1%; Logarithmic display:0.01dBm |
| VFL Wavelength | 1650nm |
| Uncertainty | ±5% |
| VFL Power | 5/15 /20/30(optional) |
| Frequency Identification | 0, 270, 1000, 2000Hz |
| Wireless Module Type | 4G (optional) |
| Data Storage | 100(PCS) |
| Input Voltage | 3~5V |
| Automatic Shutdown | 10min |
| Power Supply | 5 batteries *2 (optional), rechargeable lithium battery (optional), external inputs |
| Continuous Workingtime of Battery | 20h |
| Instrument Size | 142*73*31mm |
| Net Weight of Meter | 375~455g |
