Optical Time Domain Reflectometry
Optical Time Domain Reflectometry (OTDR) is a technology used to test the integrity of optical fibers by measuring the time and intensity of light reflected along the fiber. It is essential for fiber optic network installations, troubleshooting, and maintenance.
Home >
Product Advantage
Fiber Optic Fault Finder
Determine the Location of the Fault Point
Strong Red Light with Strong Penetration
Test the Repair Status of Fiber Optic Cables
Test Fiber Length
Test the Distance Between Two Nodes of the Fiber Optic Cable
Specifications
- SGOT04
- OTDR-105
GUANGYAN-SGOT04
SGOT04 Optical Fiber Ranger is a lightweight and accurate tool for detecting reflection events and locating fiber faults over long distances. It integrates OTDR and VFL functions, making fiber maintenance fast and efficient.
Learn More
| Model | SGOT04 | |
| Working Wavelength | 1550nm | |
| Fiber Type | 9/125um Single Mode | |
| Connector Type | FC/PC | |
| Sensor Type | InGaAs | |
| Laser Peak Power | >60mW | |
| Maximum Display Distance | Reflection event | 60km(>1dB) |
| Non | 20km(>2.5dB) | |
| Unit Of Measurement | m | |
| Reflection Event Blind Area | 15m | |
| Accuracy (reflection event) | ± (2m+2*10-4 Distance) | |
| VFL Wavelength | 650nm | |
| VFL Power | >1mW | |
| Power Supply | 3*1.5V AA Alkaline battery | |
| Battery Working Hours | ≥5000 Measurements | |
| Operating Temperature | -5-40℃ | |
| Storage Temperature | -10-60C | |
| Humidity | 0-85%(Non-condensing) | |
| Weight (without Battery) | 350g | |
GUANGYAN-OTDR-105
Multi-function MOT-50 OTDR is an essential tool for fiber length, network and camera testing. OTDR displays the power of the returned signal related to distance. The information can be used to confirm the transmission quality of a fiber optic link.
Learn More
| Model | A105 | ||
| Size & Display | 5.55 inch OLED touch screen,1280×720 resolution | ||
| Power Output | 5V 1A power output, as power bank. | ||
| UTP Cable Test | Test UTP cable connection status and display on the screen. Read thenumber on the screen.Detect the near-end, mid-end and far-endfault point of RJ45 cable connector, also can test shield cable | ||
| Length Measurement | Network cable length measurement, up to 3km | ||
| Optical Power Meter | Wavelength:1625nm,1550nm,1490nm,1310nm,1300nm,850nm,measurement range,-70 ~+6dBm, for optical power testing andFiber link loss relative measurement | ||
| Visual Fault Locator | 10mW visual fault locator with 650nm wavelength, emit red lasersources to test multi-mode and single mode fiber’s bending andbreakage, test range 8KM | ||
| Output Wavelength | 1550 | 1310/1550 | 1610 |
| Output Power | -5dBm~0dBm adjustable | ||
| Frequency | 270Hz/330Hz/1kHz/2kHz | ||
| Stability | CW, ±0.2dB/15min (test after boot for 15min) | ||
| External Power Supply | Type-C 5V (2A) | ||
| Battery | Built-in 3.7V Lithium ion battery,4000mAh. | ||
| Rechargeable | After charging 3 hours, normal working time 6 hours | ||
| Operation Setting | Language: English, Chinese | ||
| Auto Off | 5-30(mins) | ||
| Working Temperature | -10℃—+50℃ | ||
| Working Humidity | 30%-90% | ||
| Dimension/Weight | 183mm×110mm×36.5mm/0.45kg | ||
